757246 GATE VALVE ANSI 125 CAST IRON, BRONZE TRIM FLANGED #1800 8"

757246 GATE VALVE ANSI 125 CAST IRON, BRONZE TRIM FLANGED #1800 8
规格参数 参数值
IMPA编码 757246
产品单位 PCE
产品规格 Cast iron gate valves with solid wedge, bronze seats, pressure rating 125 lbs, full bore, rising stem, non-rising handwheel, bolted bonnet with yoke, flat flanges acc. to ASME B16.1 (125#), face to face acc. to ASME B16. 10, complies with requirements of MSS SP-70.
中文汉化 757246 截止阀 ANSI 125 铸铁，黄铜配件，法兰连接，1800 系列，8
物料版本

以上内容为自动翻译的内容，仅供参考

This content is automatically translated and is for reference only.
