757271 GATE VALVE ANSI 300 CARBON STL, S.STEEL TRIM FLANGED #1870 2"

规格参数	参数值
IMPA编码	757271
产品单位	PCE
产品规格	Cast steel gate valves with flexible wedge, stainless steel seats, pressure rating 150 lbs and 300 lbs, full bore, rising stem, non-rising handwheel, bolted bonnet with yoke, flanged connection acc. to ASME B16.5 (“raised face – smooth finish”), face to face acc. to ASME B16.10. On request, supplied including EN 10204 3.1.B material and test certificate. Application : steam, water, oil, vapours and gases.
中文汉化	757271 带碳钢阀体和不锈钢阀座、ANSI 300 级的法兰式闸阀，型号为#1870。这款阀门采用铸钢材质，配备柔性截面楔形，不锈钢座椅，工作压力等级为150磅和300磅，全通径设计，升起式阀杆，非升起式手轮，带有轭型固定阀盖，法兰连接符合ASME B16.5标准（“凸面-光面”），面对面连接符合ASME B16.10标准。如需，可提供EN 10204 3.1.B材料证明和测试证书。适用范围包括蒸汽、水、油、蒸气和气体。
物料版本

以上内容为自动翻译的内容，仅供参考

This content is automatically translated and is for reference only.
