757336 CHECK VALVE ANSI150 CAST STEEL, FLANGED SWING TYPE #1810 10"

757336 CHECK VALVE ANSI150 CAST STEEL, FLANGED SWING TYPE #1810 10
规格参数 参数值
IMPA编码 757336
产品单位 PCE
产品规格 Cast steel swing type check valves, stainless steel seat, pressure rating 150 lbs and 300 lbs, straight pattern, full bore, bolted bonnet, flange sizes acc. to ASME B 16.5 (“raised face – smooth finish”) and face to face acc. to ASME B16.10. Suitable for horizontal and vertical (upward flow) installation. On request, supplied including EN 10204 3.1B material and test certificate. Application: Steam, water, oil, vapours and gases.
中文汉化 757336截止阀ANSI150铸钢，焊接式，型号#1810 10英寸铸钢焊接式截止阀，不锈钢座，压力等级为150磅和300磅，直通型，全通径，带螺栓连接的顶盖，法兰尺寸根据ASME B 16.5（“凸面-光洁表面”）和面对面连接根据ASME B16.10标准。适用于水平和垂直（向上流动）安装。如需，可提供EN 10204 3.1B材料证明和测试证书。应用范围：蒸汽、水、油、蒸气和气体。
