792607 BATTERY NICKEL-CADMIUM ALCAD, LCE22P 22AH

792607 BATTERY NICKEL-CADMIUM ALCAD, LCE22P 22AH
规格参数 参数值
IMPA编码 792607
产品单位 PCE
产品规格 Alcad’s robust Ni-Cd pocket plate technology is particularly well suited to the complex requirements of installations in difficult and demanding conditions, and in remote and inaccessible locations. Alcad Single Cell nickel-cadmium (Ni-Cd) batteries offer the versatility to industry where reliable performance is crucial, even under extreme operating conditions, for example in :• Refineries • Power plants • Onshore and offshore oil & gas applications • Substations • Airports • Building infrastructure If primary power sources fail, Alcad batteries enable your backup system to provide vital systems support to keep operations moving until primary power is restored or a controlled shutdown can be performed, including for : • UPS (Uninterruptible Power Supply) • Switching and transmission • Emergency and security • Industrial fire monitors and alarms • Process control • Substation switchgear • Signaling For generator starting or switching on heaters, pumps and other essential equipment in an emergency, Alcad batteries meet the specific need for high discharge, instant voltage recovery and reliable operation, even in extreme temperatures. The LCE range has the thickest plates and is designed for applications where the battery is required to provide a reliable source of energy over relatively long discharge periods. Normally, the current is relatively low in omparison with the total stored energy and the discharges are generally infrequent. Typical uses are power backup, communications and bulk energy storage. Capacity range : 10 Ah – 375 Ah. Alcad has developed a series of standard layouts in which a battery may be ordered. Whether the battery is being installed on a rack, in a cabinet or is simply freestanding, the same configuration principles can be applied. Recommended charging voltage: For two level charge: • Float level: 1.42 ± 0.01 V/cell for LCE • High level: 1.47 - 1.70 V/cell for LCE, A high voltage will increase the speed and efficiency of the recharging. For single level charge: 1.43 - 1.50 V/cell.
中文汉化 792607 电池镍镉ALCAD, LCE22P 22Ah Alcad的坚固的镍镉口袋板技术特别适合于在困难和苛刻条件下的安装，以及偏远和难以到达的位置。 <行业多功能性> Alcad单节镍镉（Ni-Cd）电池为关键性能要求提供行业多功能性，即使在极端操作条件下，例如：•炼油厂•发电厂•陆上和海上石油&天然气应用•变电站•机场•建筑基础设施 <备用电源应用可靠性> 当主要电源失效时，Alcad电池能够使您的备份系统为保持运营直至主电源恢复或可以执行控制性关闭的重要系统提供支持，包括：•不间断电源（UPS）•开关和传输•紧急和安全•工业火灾监视器和警报•过程控制•变电站开关设备•信号指示 <启动应用的安全性> 对于发电机启动或在紧急情况下切换加热器、泵和其他关键设备，Alcad电池满足特定需求，提供高放电、瞬时电压恢复和可靠的运行，即使在极端温度下也是如此。LCE系列具有最厚的极板，专为需要电池在相对较长的放电期间提供可靠能源的应用设计。 通常，与总储存能量相比，电流相对较低，并且放电通常是不频繁的。典型用途包括备用电源、通信和大量能量存储。容量范围：10 Ah - 375 Ah。 <标准布局> Alcad已经开发了一系列标准布局，可以在这些布局中订购电池。无论电池是安装在机架上、柜子里还是仅独立放置，都可以应用相同的配置原则。推荐充电电压：对于两阶段充电：•浮充水平：LCE的每个电池1.42 ± 0.01 V•高充水平：LCE的1.47 - 1.70 V，高电压将增加再充电的速度和效率。对于单阶段充电：1.43 - 1.50 V/个。
