695319 HELI-SERT STAINLESS STEEL, FINE M10 X 1.0 X 25MM

695319 HELI-SERT STAINLESS STEEL, FINE M10 X 1.0 X 25MM
规格参数 参数值
IMPA编码 695319
产品单位 PCE
产品规格 Made of stainless steel or bronze. Instead of building up a thread hole by welding worn out threads or using bushes for rethreading, you just have to clean the hole with a tap and insert these heli-serts. Tightening procedure is the same as with the original thread. The proper length of the heli-sert should usually be 1 – 2 times the length of the standard bolts being used. Kind of thread: Nominal size, Metric coarse M2.2-M36, Metric Fine M8-M30, Whitworth Coarse W1/4-W1-1/2, Unify Coarse U No.2-U1-1/2, Unify Fine U No.6-U1-1/2, Parallel pipe thread 3/8 3/4
中文汉化 695319 带有不锈钢或青铜材质的HELISERT细螺纹M10 x 1.0 x 25mm。它无需通过焊接磨损的螺纹或使用衬套重新攻丝，只需清理孔洞后插入HELISERT即可。紧固方式与原生螺纹相同。通常情况下，HELISERT的适当长度应为标准螺栓长度的1-2倍。类型包括：公称尺寸，米制粗牙M2.2-M36，米制细牙M8-M30，惠特沃思粗牙W1/4-W1-1/2，统一粗牙U No.2-U1-1/2，统一细牙U No.6-U1-1/2，以及平行管螺纹3/8和3/4英寸。
